| CPU |
Intel® Ivy Bridge Desktop LGA1155 (Socket H2) (Max. TDP at 65W) |
| BIOS |
AMI 64Mbit SPI BIOS |
| System Chipset |
Intel® Panther Point (Intel® B75 Chipset) |
| I/O Chip |
NuvoTon NUT6106D Support 6 COMs, Fintek F81216AD for 4 COMs |
| System Memory |
Two 204-pin DIMMs Socket Support Up to 16GB DDR3/ DDR3L (Jumper Selectable) 1333/ 1600 SDRAM |
| Watchdog Timer |
Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step |
| H/W Status Monitor |
Monitoring System Temperature, Voltage with Auto Throttling Control |
| Buzzer |
Buzzer Onboard |
| Expansion |
1 x Mini PCIe (Mini PCIe and mSATA SSD Switch Through Jumper) |
