1. Socket M, support Intel Core 2 Duo / Core Duo / Core Solo / Celeron M Mobile processor
2. Intel 945GM/945GME + ICH7M
3. 2 x SO-DIMM DDRII 400/533/667 up to 4GB
4. 2 x Marvell PCI-E Gigabit Ethernet controllers
5. 4 x RS232, 8 x USB2.0
6. Dual channel 24-bit LVDS
7. 1 x PCI slot / CompactFlash socket

>> System

Processor                           Socket M, support Intel Core 2 Duo / Core Duo / Core Solo / Celeron M

Chipset                               Intel 945GM/945GME + ICH7M, 533/667MHz FSB

DRAM                                  2 x 240PIN DDRII 400/533/667 max up to 8GB

BIOS                                   4MB Award BIOS

Power Supply                       Support ACPI v2.0 specification

Watchdog                            Watchdog timer function

Dimension                           170mm x 170mm

>> I/O Ports

HDD                                    1 x IDE devices ATA100;  2 x SATA
